Corrosion is a persistent enemy of metallic structures, especially in marine or buried environments. To fight corrosion, engineers often rely on protective coatings mixed with cathodic protection (CP) systems.
However, a phenomenon known as cathodic disbondment can undermine the effectiveness of those shielding measures, leading to coating failures and multiplied corrosion.
What is cathodic dissociation?
Cathodic bonding is the loss of adhesion between the coating and the base metal. It mainly occurs in systems under cathodic protection, where a sacrificial anode is connected to the protected structure to prevent corrosion.
If there are defects or holidays in the coating (small areas where the coating is missing), the exposed metal contacts the surrounding electrolyte. Cathodic reactions arising at these locations can lead to collapse of the defect coating.
Cathodic bonding mechanisms
Several factors contribute to the isolation of minerals:
Formation of hydroxyl ions
In the metallurgical region below a defect, the cathodic reduction of water or oxygen generates hydroxyl (OH-) ions. These ions raise the pH in the area, alkalizing the environment.
Weak adhesion
A high pH environment can attack the chemical bonds that cause the coating to adhere to the metal, resulting in weak bond strength and bond breakdown.
Osmotic Pressure
An increase in the concentration of ions at the interface attracts water by osmosis. This can cause the fabric to wrinkle and tighten further.
Hydrogen Conversion
If the cathode protection potential becomes too negative, hydrogen gas can begin to build up in the metallic layer. This gas can put pressure on the fabric, which can cause sealing.
Factors Influencing Cathodic Disbondment
- Coating Type: Some coatings are more prone to cathodic disbondment than others. Factors like coating composition, permeability, and adhesion energy all play a position.
- Cathodic Protection Potential: Overprotection, or excessively terrible CP potentials, can increase the fee of cathodic disbondment.
- Environment: Temperature, electrolyte composition (e.G., seawater vs. Soil), and the presence of microorganisms can have an impact on the severity of disbondment.
- Surface Preparation: Inadequate surface training before coating software can go away behind contaminants or create a negative floor profile, weakening the coating’s adhesion.
Testing for Cathodic Disbondment
Standard tests are available to evaluate the resistance of a coating to cathodic disbondment.
These tests generally require:
- Deliberate introduction of a defect in the coating.
- Immersion of the coated sample in an electrolyte under cathodic protection.
- Measure the radius of disbondment around the defect after a certain time.
Common testing standards include ASTM G8, ASTM G42, and NACE TM0115.
Cathodic Disbondment Prevention
- Coating Selection Proper Coating: Select coatings with proven resistance to cathodic disbondment, especially for areas where CP is used.
- Excellent Surface Preparation: Be sure to thoroughly clean and condition the underlying metal surface before coating.
- Optimized CP Design: Avoid overprotection by careful selection of anode materials and control of CP capacity.
- Routine Inspection and Maintenance: Regular inspections help identify early signs of cracks, allowing for timely repairs and mitigation.
Example: Cathodic corrosion in pipelines Buried pipelines are often protected by coatings and cathodic protection systems. However, soil moisture can penetrate through coating defects, and cathodic reactions at these surfaces can cause bond breakdown. Loss of adhesion around the pipeline can result in rapid corrosion of the unbonded coating, which can result in leakage or damage.
Conclusion
Cathodic corrosion is an important issue for engineers and property owners concerned about corrosion protection. It is important to understand the processes, influencing factors, testing methods and preventive measures to ensure the long-term consistency of metal coatings in different industries.
